Plastic Processed:
PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, EVA, HDPE, MLLDPE, EPS, PA, Polystyrene, PE, LDPE, EVOH, HDPE/PP, ABS/PP, PE/PP
Condition:
New
Style:
Horizontal
Distance Between Tie Bars(Width)(mm):
580mm
Distance Between Tie Bars(Height)(mm):
580mm
Mold Height(mm):
220 - 600 Mm
Ejector Stroke(mm):
160 Mm
Ejector Force(kN):
77 KN
Theoretical Shot Volume(cm³):
595 Cm³
Injection Rate (g/s):
212 G/s
Machine Type:
Hydraulic
Injection Weight (g):
542 G
Screw Diameter (mm):
53 Mm
Distance Between Tie Bars:
580mm*580mm
Weight (KG):
8500
Place Of Origin:
Zhejiang, China
Open Stroke(mm):
560 Mm
Model Number:
HMD268M8/M8-S
Brand Name:
HMD
Power (kW):
45 KW
Warranty:
1 Year
Key Selling Points:
Multifunctional
Applicable Industries:
Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops
Showroom Location:
Turkey, Indonesia, Mexico, Russia, Malaysia
Marketing Type:
New Product 2020
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Warranty Of Core Components:
1 Year
Core Components:
PLC
Screw Stroke:
270mm
Screw Speed(stepless):
0~180r/min
Platen Size:
850mm*850mm
Max.daylight:
1160mm
Hydraulic Ejection Force:
77KN
Hydraulic System Pressure:
17.5MPa
Pump Motor:
22/28.7KW
Heating Capacity:
18.2KW
Plastic Type:
Thermoplastic
Clamping Force (kN):
2680 KN
After-sales Service Provided:
Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support
After Warranty Service:
Video Technical Support, Online Support
Local Service Location:
Turkey, Indonesia, Mexico, Russia, Malaysia
